HY-R4000 Long Range Distance RFID UHF Android Bluetooth Wifi Handheld RFID Tag Reader

FOB Reference Price:Get Latest Price
US $450-1,000 / Pieces | 1 Piece/Pieces UHF RFID Reader (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
RFIDHY
Model Number:
UHF RFID Reader
Product Name:
UHF RFID Reader
Dimensions:
192mm x 87mm x 151mm/ 7.56 x 3.43 x 5.94in
Weight:
456g/ 16.08oz
Display:
4'' WVGA (480*800), 16.7M colors
Touch Panel:
Rugged capacitive touch panel
Expansion Slot:
1 PSAM, 1 SIM, 1 MicroSD(TF) slot
Interfaces:
USB Micro-B
Audio:
0.5W speaker, build-in microphone
Keypad:
4 TP touch key-press buttons
Sensors:
Light Sensor, Proximity Sensor
Supply Ability
Supply Ability:
3000 Piece/Pieces per Month UHF RFID Reader
Packaging & Delivery
Packaging Details
HY-R4000 Long Range Distance RFID UHF Android Bluetooth Wifi Handheld RFID Tag Reader
1 piece in a sigle box, 100pcs per carton
Port
Shanghai, Shenzhen, Ningbo, Qingdao, etc.
Lead Time :
7~10 days after receipt of payment

HY-R4000 Long Range Distance RFID UHF Android Bluetooth Wifi Handheld RFID Tag Reader

Specification



 Physical Characteristrics
 Dimensions 192mm x 87mm x 151mm / 7.56 x 3.43 x 5.94in
 Weight 456g / 16.08oz
 Display 4'' WVGA (480*800), 16.7M colors
 Touch Panel Rugged capacitive touch panel
 Power Main battery: Li-ion, 3200mAh
 Pistol battery: Li-ion, 5200mAh (Optional)
 Expansion Slot 1 PSAM, 1 SIM, 1 MicroSD(TF) slot
 Interface USB Micro-B
 Audio 0.5W speaker, build-in microphone
 Keypad 4 TP touch key-press buttons
 Sensors Light Sensor, Proximity Sensor
Professional UHF RFID Reader Factory here now. OEM and ODM One-stop service Customized, happy send sample to you confirm quality. https://hyrfid.en.alibaba.com ; marketing @rfidhy.com



 Performance
 CPU Cortex-A7 1.3GHz quad-core
 RAM 1GB
 ROM 4GB
 EXpansion Supports up to 32GB Micro SD card
 Developing Environment
 Operating System Android 4.4.2
 SDK RFIHYD Software Development Kit
 Language Java
 Tool Eclipse / Android Studio
 User Environment
 Operating Temp. 14°F to 122°F / -10°C to 50°C
 Storage Temp. -40°F to 158°F / -40°C to 70°C
 Humidity 5%RH - 95%RH non condensing
 Drop Specification Multiple 1.2m drops to concrete across the operating temperature   range
 Tumble Specification 1000 x 0.5m/1.64ft falls at room temperature
 Sealing IP64
 Communication
 WLAN IEEE802.11 b/g/n
 WWAN  GSM/GPRS/EDGE Quad Band  (850/900/1800/1900MHz)
 WCDMA (850/1900/2100MHz)
 Bluetooth  Bluetooth 4.0
 GPS GPS, AGPS
Good UHF RFID Reader Factory Supplier save you time and money, help your win market.
Contact us: huayuan @rfidhy.com



 Barcode Scanning (Optional)
 1D Linear Scanner
 1D Laser/CCD IEEE802.11 b/g/n
 Symbologies UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5,   Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
 2D Imager Scanner
 2D CMOS Laser   Scanner IEEE802.11 b/g/n
 Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR   Code, Micro QR Code, Aztec, MaxiCode; Postal Codes: US PostNet,   US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal   (KIX), etc.
 RFID (UHF)
 Frequency 865MHz-868MHz / 920-925MHz / 902-928MHz
 Protocol EPC C1 GEN2 / ISO18000-6C
 Antenna Linear polarization (1.8dBi)
 Circular polarization (2.5dBi)
 Power 1W (+10dBm to +30dBm)
 R/W Ranges Option1 (R2000), up to 4.5m
 Option2, up to 2m (Ranges depend on tags and environment)
 Reading Rates 200 tags/s
 Biometric (Optional)
 Functions Android 4.4.2
 Sensor RFIDHY Software Development Kit
 Sensor Type Java
 Resolution Eclipse / Android Studio
 Memory 1,000 PCC fingerprints
 PSAM (Optional)
 Slots 2 PSAM slots (maximum)
 Protocal ISO7816
Professional UHF RFID Reader Factory here now. OEM and ODM One-stop service Customized, happy send sample to you confirm quality. https://hyrfid.en.alibaba.com ; marketing @rfidhy.com

Click for More Information !!!

Product Description

HY-R4000 UHF Handheld RFID Reader provides high performance UHF RFID reading/writing capability. It is designed to support EPC C1 GEN2 / ISO18000-6C protocol, and equipped with class leading R2000 UHF module or cost-effective UHF module that covers frequency ranges for most areas. This versatile device can also be configured with class leading high performance 1D/2D barcode scanning and a variety of wireless connections such as Bluetooth, 3G, and WiFi. With its highly customizable ability, enterprises can deploy this single device in many areas, including asset management, retail, warehouse management, fleet management and etc.

Applications:

- Asset Management
- Warehouse Management
- Retail
- Fleet Management
- Laundry Management
- Power Meter Reading



UHF RFID Reader

UHF RFID Reader

UHF RFID Reader

UHF RFID Reader

UHF RFID Reader

UHF RFID Reader

UHF RFID Reader

UHF RFID Reader

UHF RFID Reader

Click for More Information !!!

Features



  • Most Powerful Application Performance
The HY-R4000 UHF is based on Android 4.4.2 system, features the fast and powerful quad core 1.3GHz processor, together with 1GB of RAM, 4GB build-in flash storage, plus a SD card slot that can add up to 32GB of memory.
  • Superior UHF RFID Reading Capability
The HY-R4000 UHF provides new levels of UHF RFID reading performance. It can be configured with class-leading R2000 UHF module or cost-effctive UHF module, together with two kinds of high performance antenna options.
  • Extensive Data Capture Functions
The HY-R4000 UHF can also be integrated with best-in-class Zebra 1D/2D barcode scanning engine, sensitive fingerprint snap-on and GPS. It allows users to choose data collection options as per industry need.
  • Fast Wireless Connectivity
Whether indoors or outdoors, theHY-R4000 UHF provides fast and stable network connectivity with a variety of wireless connections including WCDMA, WiFi, Bluetooth and GPRS.
  • Powerful Battery
With the embedded 3200mAh main battery and the 5200mAh pistol battery, the HY-R4000 UHF enables non-stop operation over the full working day.
  • Highly Customizable
From a single function device to a fully featured enterprise mobile computer, this device delivers the best possible flexibility and diversity to satisfy a whole variety of application needs.
Professional UHF RFID Reader Factory here now. OEM and ODM One-stop service Customized, happy send sample to you confirm quality. https://hyrfid.en.alibaba.com ; marketing @rfidhy.com
Related Products

UHF RFID Reader



 Click for More Information !!!

Company Information

When the Smart Card industry kicked off in mainland China 20 years ago, RFIDHY were at the forefront. In 1995, we began by producing plastic magnetic cards. We are the first supplier of magnetic cards as the ticket for AFC (Automatic Fare Collection) system for Shanghai Metro No1 line. Our products line covered Plastic card, Smart cards, Contactless cards, RFID inlay and RFID products tags with growing of technology and applications in this area. Our experience is not only in RFID products R & D, but also system and solution design, and system integration manufactures, but also development. Our success in oversea market was apparent – from the first client in Spain in Europe in 2005, and expanded to hundreds of clients covering up to 100 countries and regions in several years.



RFIDHY had also established good and strategic partnership with many international leaders in Smart Card and RFID industry.



Our owned subsidiary locates in Shenzhen (Shenzhen Huayuan Smart Technologies Co., Ltd) have full sets of production line of RFID Products which have been approved by IC certification and ISO9001:2008 certification.



Now hundreds of millions of pieces of RFID products have been supplied to our clients and partners around the world which have widely been used to public transportation, retail, library, transportation, NFC and more.



Our Advantages:

    1. 22 years’ experience in rfid and nfc products manufacturing.
    2. 12 years of experience in International trade, serving customers with more than 100 countries and regions.
    3. Short delivery time, stock delivers in 2 or 3 days.
    4. Strong technical strength, can quickly resolve customer problems.
    5. Also, OEM/ODM service are available.






Click for More Information !!!
